DC-DC converters. Analysis, design, experiments

Descriere

Cartea oferă o abordare structurată și orientată spre aplicații a studiului convertoarelor de comutare DC-DC, cu accent atât pe înțelegerea teoretică, cât și pe experimentele practice. Volumul este conceput special pentru studenți, ingineri electroniști, profesioniști în electronică aplicată și, în general, pentru oricine este interesat să înțeleagă conceptele fundamentale legate de convertoarele DC-DC utilizate în sursele de alimentare din echipamentele electronice.

CUPRINS

PREFACE

1. INTEGRATED CIRCUITS FOR PWM CONTROL OF DC-DC CONVERTERS

- LABORATORY TASKS

- QUESTIONS

1. CIRCUITS FOR DRIVING FLOATING AND NON-FLOATING MOS TRANSISTORS

- THE POWER MOS TRANSISTOR

- INTEGRATED CIRCUITS FOR DRIVING FLOATING AND NON-FLOATING MOS TRANSISTORS

- THE IR21XX CIRCUIT

- ADVANTAGES, DISADVANTAGES, AND LIMITATIONS OF THE CIRCUIT

- APPLICATION SCHEMATICS OF THE CIRCUIT

- EXPERIMENTAL STUDY

- QUESTIONS

III. THE BUCK CONVERTER

- DESCRIPTION OF THE SCHEMATIC

- EXPERIMENTAL STUDY

- QUESTIONS

1. THE BOOST CONVERTER

- ARCHITECTURE DESCRIPTION

- EXPERIMENTAL STUDY

- QUESTIONS

1. TWO-TRANSISTOR BUCK-BOOST CONVERTER WITH POSITIVE OUTPUT VOLTAGE

- DESCRIPTION OF THE SCHEMATIC

- EXPERIMENTAL STUDY

- QUESTIONS

1. LINEAR VOLTAGE REGULATOR OF LDO TYPE

- DESCRIPTION OF THE SCHEMATIC

- EXPERIMENTAL STUDY

- QUESTIONS

VII. HIGH FREQUENCY INDUCTOR AND TRANSFORMER

- THE TRANSFER OF AN IMPENDACE THROUGH AN IDEAL TWO WINDINGS TRANSFORMER

- HIGH FREQUECY INDUCTOR

- EXAMPLE OF ESTIMATING THE NUMBER OF TURNS OF A COIL/INDUCTOR

- COUPLED INDUCTORS. THE REAL TRANSFORMER WITH TWO WINDINGS

- EXPERIMENTAL DETERMINATION OF THE PARAMETERS OF A TRANSFORMER WITH TWO IMPERFECTLY COUPLED INDUCTORS

VIII. RULES FOR STEADY-STATE ANALYSIS OF CCM OPERATED DC-DC CONVERTERS

1. ANALYSIS AND DESIGN OF THE SHEPPARD-TAYLOR CONVERTER

- ANALYSIS AND DESIGN REQUIREMENTS

- DESIGN OF THE CONVERTER

- QUESTIONS

APPENDICES

REFERENCES
